Ferrite Bead Dc Resistance . in essence, any dc current flowing through the ferrite bead will create a voltage drop in proportion to the dc. the black line indicates the overall impedance, which (though not shown in the plot) starts at r series, otherwise known as the bead’s dc resistance. It then increases linearly during the inductive frequency range, levels off at 300 mhz, and then begins to decrease before leveling off at 1.1 ghz. The ac resistance (r ac) is the peak. 100k+ visitors in the past month the dc resistance (r dc), which is 300 mω, is acquired from the manufacturer's data sheet. Take into account the dc resistance of the ferrite bead. since the resistive component of the impedance dominates at resonance due to the cancellation of the inductive and capacitive.
